IROAD X9 Dash Cam 32G

IROAD X9 2-CH Dash Cam
The award winning IROAD X9 dash cam is a Full HD 1080p 2-channel system recording at 30FPS, with the widest camera lens in this category of dash cams. This system packs high video quality and built-in Wi-Fi capabilities into a small sleek design. It also comes jam-packed full of fantastic features like X-Vision, parking mode and Advanced Driver Assistance Systems, which will be sure to please any dash cam owner.
FEATURES
2CH Front & Rear – Full HD 1920×1080 at 30fps
ARM Cortex-A7 MP Core Processor V3
Front – SONY STARVIS Image Sensor
Rear – SONY Exmor Image Sensor
150° Wide angle
ADAS – Advanced Driver Assistance Systems
X-VISION: Intelligent Night Vision
2.9W – Minimum Power Consumption
Wi-Fi Function: Live Screen, Playback, Settings, Update
Format Free & Memory Automatic Recovery System
SafeGuard: (Battery Discharge, High Temperature)
Parking Recording (Motion Detect, Impact Recording)
Voice Guidance & Recording
External GPS Antenna

FRONT IMAGE SENSOR SONY STARVIS
REAR IMAGE SENSOR SONY EXMOR
INTELLIGENT NIGHT VISION
FRONT – FHD REAR – FHD
ROAD SAFETY WARNING SYSTEM
WIFI CONNECTION & IROAD APP
ROTATABLE LENS 90º
2.9W MINIMUM POWER
150º WIDE ANGLE
BATTERY DISCHARGE PREVENTION
FORMAT FREE AUTO RECOVERY
FRONT – 30FPS REAR – 30FPS

SONY STARVIS Image sensor
SONY STARVIS premium image sensor guarantees the ultimate sharpness and night image quality.IROAD X9 is equipped with Sony Starvis image sensor to record the brightest and the cleanest images even in low-light environments; it provides a much brighter and clearer image compared to viewing with bare eyes.

X-VISION
Intelligent NIGHT VISION for IROAD
In parking mode, the surrounding brightness is automatically diagnosed within 5 seconds and the recording brightness will be set to 3 times higher when the surrounding illumination is low. It can record bright and clear images not only in parking mode but also in driving mode.

ADAS
Advance Driver Assistance Systems
The IROAD X9 is equipped with the Road Safety Warning System that provides audio and visual alerts for Lane Departure (LDWS), Front Collision (FCWS) and Front Vehicle Departure (FVDW).
It detects road markings and gives voice warnings to the drivers if the vehicle begins to stray from its lane or when it is at risk of an imminent crash.
LDWS
Lane Departure Warning System
LDWS operates in a way that the front camera recognises the road lane in real time and, if the driver falls asleep while driving or drives poorly, causing the car to depart the lane, it will notify about it through the preset warning sound.
FCWS
Forward Collision Warning System
The FCWS function calculates the average distance from the vehicle in front and alerts the driver in advance when reaching the range of safe breaking distance in order to prevent a collision.
FVDW
Front Vehicle Departure Warning
Front Vehicle Departure Warning is for generating a warning once the vehicle in the front stops and waits for a signal or starts. Intelligent smart system for driver’s convenience!

Wi-Fi
Easily connect to the dash cam via Wi-Fi to view footage and make changes to the settings.
Automatic Wi-Fi Connection
Automatically connects to the dash cam after opening the IROAD app
Live View
Easily adjust the lens using live view for the front and rear cameras
Footage Playback
Playback saved footage straight from your smartphone
Quick Download
Download all the saved footage on your memory card
Adjust Settings
Adjust all settings using your smartphone
Easy Setup
Simply download the app to get instant access to the dash cam
FORMAT FREE
The Most Stable System
The file system improved in stability by utilising the JDR system. Recordings are automatically saved in the main memory unit and are safer than previously-used formats. JDR format does not require formatting regularly, and automatic rebooting function guarantees the safety of the device and data.
DATA RECOVERY
Auto Recovery System
Saved images can be memorised and restored with the auto recovery system. In addition, by allocating the data to a certain size, the user can arbitrarily adjust the data to be recorded and allocate space according to the size.
LBP
Battery Discharge Prevention Function
For the purpose of battery protection, it automatically detects and cuts off voltage when the voltage drops below a certain point. Once initiated, recording is stopped and power is Turned Off. The motion detection function is effective for saving battery.

GENERAL SPECIFICATIONS:
IROAD X9
DIMENSION 110 x 48 x 20 mm
WEIGHT 83g

DETAILED SPECIFICATIONS
IROAD X9
CAMERA
Front: SONY STARVIS 2.13M Rear: SONY Exmor 2.0M
RESOLUTION
Front & Rear: Full HD (1920 x 1080P)
FRAME
Front & Rear: 30fps
DEGREES
Front: 150º Rear: 145º
CPU
ARM Cortex-A7 MP Core Processor V3
X-VISION
In parking mode, set automatically brightness 3 times more
WI-FI
Smartphone playback/settings, Firmware automatic upgrade
ADAS
LDWS(Lane departure warning system) FCWS(Forward collision warning system) FVDW(Front Vehicle Departure Warning)
LBP
Cut-off and booting voltage settings(Constant power)
G SENSOR
Axis Accelerometer G-Sensor (3D, ±3G)
GPS
External GPS Antenna ((In conjunction with Google Maps to check the location and speed)
CAPACITY
Micro SD 4GB ~ 128GB (recommended type MLC Class10)
RECORDING MODES
Normal(driving)mode, Event(impact)mode, Parking(Motion Detection) mode, Voice recording
AUDIO
Speaker (Effect sound for informing operational status and 34 kinds of voice guidance supported), Microphone embedded.
VIDEO
H.264 / ADPCM
TEMPERATURE
-30 ~ 80 º C (Storage temperature : -30 ~ 90 º C)
HUMIDITY
10 ~ 95%
ETC
Security LED / Operation Status LED/ GPS Receiver LED
PC VIEWER
Windows Xp, VISTA, Win7, Win8 (32Bit ~ 64Bit support)
APPLICATION
IROAD App (Android 2.3, iOS 5.0 or higher version)
